Three Comprehensive Test Chamber

Three comprehensive Test Chamber mainly for aerospace, aviation, petroleum, chemical, electronics, communications and other scientific research and production units to provide temperature and humidity change environment. At the same time, in the electric vibration stress on the Test Chamber, for the user for the machine (or parts), electrical appliances, instruments, materials, temperature, vibration comprehensive stress screening test, in order to assess the adaptability of the test article or to evaluate the behavior of the test article. Compared with the effect of a single factor, it can more truly reflect the adaptability of electrical and electronic products in the process of transportation and actual use to the temperature and humidity and vibration composite environment changes, and expose the defects of products, which is an essential and important test means for the whole process of new product development, prototype test and product qualification identification test.

Item No :
THV-500
Order(MOQ) :
1
Product Origin :
Dongguan
Color :
White

Inquire Now

Product categories

Email Us

Tel Us Get A quote

New Products

Three Comprehensive Test Chamber

Temperature range	RT+10℃～＋150℃
Temperature range	-40-150℃
Temperature fluctuation degree	±0.5℃
Temperature uniformity	2℃
Temperature deviation	±2℃
Humidity range	20% to 98% RH
The iation of humidity	±2.0% RH
Humidity uniformity	±3.0% RH
Humidity deviation	+ 2~ -3% (> 75% RH), ± 5% (75% RH)
Heating rate	4℃ / min (-40-105℃ linear, 5 KG aluminum ingot without heating)
Cooling rate	4℃ / min (150~ -40℃ linear, 5 KG aluminum ingot without heating)
Working volume	200L
Internal dimension	W800H800D800mm
External dimension	W1100H1710D2280mm

Environmental Battery Test Chamber

The removable USB smart stick memory allows users to easily enter data, programs, alarms, indexes and other functional options.
Comprehensive test environment of three environmental factors was simulated in the same box.
Flexibility-The Test Chamber can work with the user's existing vibration equipment or assemble new vibration devices.
Multi function can be used as a separate temperature / humidity Test Chamber to maximize your return on investment.
High performance, fast temperature variation, can be accelerated stress test.
Accept custom design to meet strict user requirements.
User-friendly control design for convenience with other user equipment. The refrigeration system is designed to protect the compressor and ensure the refrigeration performance of the Test Chamber. At the same time, refrigeration is low energy consumption, cost saving.
Humidity water filtration system to remove impurities, protect the Test Chamber.
Programming controller, RS-232 / 485 computer interface.
Studio size, temperature range, humidity range, vibration frequency and vibration mode can be made according to user requirements.

Environmental Chamber Temperature Humidity Control

Temperature and Humidity Test Chamber

Touch type programmable temperature and humidity controller

PLATINUM SERIES

It is temperature and humidity programmable controller which equips with the general control, heating and cooling function by supporting high definition TFT-LCD touch screen and SD card.

Performance：

High accuracy

Precision control with 18bit A/D convertor

TEMP. : ±0.1% of full scale ±1 digit

HUMI. : ±1.0% of full scale ±1digit

Optimizing PID group

Precision control by 6 groups of TEMP./HUMI. and 3 group of temperature only

Specialized controller

As a specialized controller for temperature and humidity, synchronized control system with PT-PT, PT-DCV

Specialized humidity control

Humidity control algorithm implements a stable control according to the equipment size。

Heating cooling control
