Our temperature forcing system offers precise and accurate thermal testing, with a temperature range from -70o C to +250o C. With an adjustable air fl ow and fast ramping, the dragon is the perfect solution for rapid heating and cooling of samples. This versatile product is perfect for a wide range of applications, including heating electronic components, sensors aircraft engineering, and any other industry which requires testing of resistance, reliability, and performance
Order(MOQ) :
1Product Origin :
FranceColor :
WhiteCustomized Machine
Specification and Parameter
| PERFORMANCE(Ambient temp: +22 °C) | |
|
Temperature range |
-70 °C to +250 °C |
|
Pull down from +125 °C to -55 °C |
14 s |
|
Thermal stability |
<+/-0.5 °C |
|
WARRANTY |
|
|
Parts |
2 years |
|
REFERENCE |
|
|
Function |
Rapid, precise and reproducible heating & cooling of samples |
|
Version |
3.1 |
|
Temperature Range |
From -70 °C to +250 °C (with arm length = 1m) |
|
Application |
Heating electronic components and circuit boards, performing climatic simulations, electronic characterization, temperature cycling, targeted freezing, aerospace and defense. |
|
GENERAL SPECIFICATIONS |
|
|
Frame dimensions (H x W x D) |
1040 x 900 x 700 mm (without electrical arm) |
|
Construction |
Electrogalvanized steel with epoxy paint |
|
Net weight |
250 kg |
|
Standard Equipment |
4 swivel casters with lock 2 easy moving handle Glass Thermo Cup (T-Cup) & nozzle n°7 Foam mat Type K thermocouple |
|
Climate class (temperature) |
From +18 °C to +30 °C |
|
Relative humidity |
< 70% |
|
Indoor / Outdoor use |
Indoor use only |
|
Environment |
Not designed for use in an explosive atmosphere (ATEX) |
|
Noise level |
< 63 dB |
|
Warranty |
2 years by FROILABO (during and after warranty period) |
|
ELECTRICAL ARM AND HEAD |
|
|
Positioning |
2 electric cylinders for vertical and horizontal positioning of the head |
|
Arm length (deployed / folded) |
900 mm / 1400 mm (from pivot to nozzle) |
|
Working height |
From 675 mm to 1270 mm |
|
Arm rotation |
270° |
|
Head cylinder |
Pneumatic for component change (fast up/down) |
|
Head rotation |
180° |
|
T-Cup dimensions |
Internal diameter : 144 mm / available height : 50 mm |
|
REFRIGERATION AND THERMAL PRODUCTION |
|
|
Refrigeration system |
2 cascade-mounted compressors with intermediate plate heat exchanger |
|
Type of regulator |
Capillary tube |
|
Refrigerant charge |
1st stage: ISCEON89 / 2nd stage: R508B |
|
Thermal production |
Electrical heating resistance |
|
PERFORMANCES (AMBIENT TEMPERATURE +22°C) |
|
|
Temperature range |
From -70 °C to +250 °C, display and setting (on air) at +/- 0.1 °C |
|
Air flow |
From 2.2 L/s to 8.4 L/s |
|
Controlled ramp |
From 0.1°C to 16°C/s |
|
Transition time without control |
From -55 °C to +125 °C /s : 7 seconds / from +125 °C to -55 °C/s : 14 seconds |
|
Head stability (AIR regulation) |
+/- 0.5 °C |
Environmental Equipment
A temperature forcing system which offers high precision and accuracy, to ensure successful thermal testing every time, with all testing in accordance to the European norm in force: EN60068-3-11.
Excellent temperature control:
With a wide temperature range, to ensure efficient testing every time.
Easy to operate, with fast return to temperature to allow for continual analysis throughout the day.
Operate between -70oC and +250oC and change temperature in a matter of seconds – for efficient testing of all temperature parameters.
Adaptable to your needs: with an adjustable air flow between 2.2 l/sec and 8.4 l/sec.
Wide variety of applications:
In many industries, it’s essential to characterize and verify product performance when subjected to temperature variations, and Froilabo’s Dragon is the perfect solution. Our versatile and stable thermal unit is perfect for a wide range of applications, from heating electronic components, to performing climatic simulations.
Applications of the Dragon include:
Heating electronic components
Heating printed circuit boards
Performing climatic simulations
Electronic characterization
Temperature cycling and targeted freezing applications
Aerospace and defence
Photo-electronics material suppliers
Plug and play technology:
The user-friendly Dragon works around your needs, to ensure maximum efficiency of your testing.
Remote connection: Easily create methods and see run status by connecting the Dragon to your computer.
Easy transportation: with a guide handle and 4 wheels for easy manoeuvring into desired location to perform testing
Adaptable to your needs: with a steerable motorized arm and head
Secure testing: with a password protected touch screen
Diversity with performance: With three working methods, manual, automatic and programmable – select the one that’s right for your application
