Setting and Maintenance of Constant Temperature and Humidity Test Chamber
Constant temperature and humidity test chamber is a relatively precise test equipment. In order to ensure the smooth completion of each test process, the power supply of the connected equipment must be stable at around 380V to ensure that the compressor will not be damaged. In addition, you must ensure the personal safety of the personnel who receive the power, so please understand the specific operation methods before wiring.
Constant temperature and humidity test chamber adjust or replace the connected power supply. After checking that the voltage of the power supply to be connected is correct, connect the neutral terminal to the neutral terminal in the distribution chamber. Ensure that the neutral line is connected, otherwise it may cause the equipment of the constant temperature and humidity test chamber to fail to work normally or burn electrical components.
After confirming that the neutral wire is connected, connect the 3 ∮ wire to the three terminals under the main switch of the distribution chamber in the constant temperature and humidity test chamber, and tighten the screws. We need to connect the ground wire, which is connected in the same way as other power cables, and directly to the ground terminal of the distribution chamber. In the process of connecting each power cord, everyone must ensure that the different colors of the power cord can be correctly identified to avoid connection errors and normal testing.
Maintenance of constant temperature and humidity test chamber:
1, Clean the water circulation system: clean the water filter, replace the filter, check the operation of the pump, including the operation of the water flow switch, adjust the water circulation flow and test operation.
2, Check all electrical wiring and electrical components to ensure reliable operation and good contact.
3, Replace the fresh air filter.
4, Refrigeration system cleaning: replace the refrigeration oil, clean the oil filter.
5, Check the vulnerable parts of the refrigeration system: check the sealing condition of the compressor and connecting parts, and replace all filters.
6, Refrigeration system leakage inspection: check all the connecting parts of the refrigeration system and the connecting parts of the valve plate are leaked and tightened.
7, According to the working conditions to supplement refrigerant: check whether the need to supplement the system refrigerant to ensure effective cooling capacity.
8, Comprehensive system operation: check whether the operating components are in good condition.
How to Control the Uniformity of Temperature and Humidity When the High and Low Temperature Test Chamber is Loaded?
High and low temperature test chamber "load" refers to the weight of our test product, or the product needs to be energized to test its heat is referred to the load. The "load" in the high and low temperature chamber is divided into non-heating load and heating load, and the test product that is not powered on or powered on is called non-heating load. This load has no effect on the temperature and humidity range of the constant temperature and humidity test chamber as a whole, but only affects the time of rising and cooling or rising and falling humidity. The test product that needs to be powered on and emits heat is a heating load, which has a relatively large impact on temperature and humidity, and the load that different temperature points or humidity points can withstand is not the same.
It is very important to select the appropriate test equipment when the product is undergoing temperature test.
1, The test range must be required to meet the product failure possibility test range, that is, whether it is a high temperature chamber or a low temperature chamber or a temperature and humidity test chamber or a thermal shock test chamber should be able to meet the extreme temperature conditions specified in the test requirements.
2, Ensure the volume of the test sample, it should not be greater than the working volume of the test equipment 1/5 of the principle standard to select the test equipment.
3, In order to ensure the uniformity of temperature in the test area, the convection mode of the test chamber is customized according to the heating power of the sample. The natural convection of hot air is used, which is especially suitable for drying powder, and most of the test equipment adopts the forced circulation of hot air. The difference in the temperature distribution of the equipment has a great impact on the test results. When a large sample is used, or the number of samples tested at the same time is large, the test results will vary greatly with the different locations, so the temperature uniformity of the equipment should be selected as best as possible. The uniformity performance of the high and low temperature alternating and humidity test chamber of the macro exhibition instrument can reach ≤0.5°C.
4, To prevent the sample heat absorption or heat release caused by heat radiation or heat load in the test area, the heating or refrigeration system device of the equipment has no effect on the temperature equalization and cooling rate of the sample during the test.
We can not be empty when using the high and low temperature test chamber, we will more or less place the test sample, and the user - generally after the test sample put into the heat is not too much concept, in order to avoid the temperature can not reach, can not fall down or rise and cool slowly this kind of situation, so we recommend that when purchasing equipment, to its heat requirements, or place the material, weight, size of the sample to tell the manufacturer, which will effectively help the test to make the test effect better.
